Product Brief:
szAMB LED lighting System provides solution for chickens to
increase egg output, lower mortality, longer peak production
period and improve animal welfare.
By using szAMB intelligent poultry LED lighting system for
raising chickens, it is benefificial for higher quantity and quality
of eggs, maturity at a faster rate and higher standard of health,
compared with way of chicken raised under traditional light
sources.
Benefits:
>Lower lighting costs and maintenance costs.
>Increase musculoskeletal development and weight gain.
>Induce earlier maturity for hens to lay eggs.
>Increase egg output and quality.
>Regulate reproduction cycles.
>Increase length of reproductive life.
| Model No. | Dimension (mm) | Power (w) | Luminous Efficiency | Lumen (LM) | CCT | CRI | Viewing Angle | Input Voltage(AC) | Light Source | LED Q’ty(pcs) | Frequency
(HZ) | Dimmable |
| 120 degree White Color (Triac Dimmable 0.2%-100%) (HZ) |
| WP2K-09WTD-S | 600 | 9 | 130-140lm/w | 1170-1260 | 3000K:3045±175k | >80 | 120o | | SMD2835 | 56 | 50/60 | Triac |
| WP4K-20WTD-S | 1200 | 20 | 130-140lm/w | 2600-2800 | 4000K:3985±275k | >80 | 120o | AC100-120V or AC200-240V | SMD2835 | 112 | 50/60 | Triac |
| WP5K-24WTD-S | 1500 | 24 | 130-140lm/w | 3120-3360 | 5000K:5029±283k | >80 | 120o | 168 | 50/60 |
| WP6K-28WTD-S | 1800 | 28 | 130-140lm/w | 3640-3920 | 6000K:6065±415k | >80 | 120o | 192 | 50/60 |
| V-shape Version with 150 degree White Color (Triac Dimmable 0.2%-100%) |
| WP2K-09WTD-V | 600 | 9 | 130-140lm/w | 1170-1260 | 3000K:3045±175k | >80 | 150o | | SMD2835 | 96 | 50/60 | Triac |
| WP4K-20WTD-V | 1200 | 20 | 130-140lm/w | 2600-2800 | 4000K:3985±275k | >80 | 150o | AC100-120V or AC200-240V | SMD2835 | 192 | 50/60 | Triac |
| WP5K-24WTD-V | 1500 | 24 | 130-140lm/w | 3120-3360 | 5000K:5029±283k | >80 | 150o | SMD2835 | 256 | 50/60 | Triac |
| WP6K-28WTD-V | 1800 | 28 | 130-140lm/w | 3640-3920 | 6000K:6065±415k | >80 | 150o | | 288 | 50/60 | Triac |
V-shape Version with 150degree White Color (0-10V
Dimmable 1%-100%) |
| WP2K-09WVD-V | 600 | 9 | 130-140lm/w | 1170-1260 | 3000K:3045±175k | >80 | 150o | | SMD2835 | 96 | 50/60 | Triac |
| WP4K-20WVD-V | 1200 | 20 | 130-140lm/w | 2600-2800 | 4000K:3985±275k | >80 | 150o | AC100-120V or AC220-240V | SMD2835 | 192 | 50/60 | Triac |
| WP5K-24WVD-V | 1500 | 24 | 130-140lm/w | 3120-3360 | 5000K:5029±283k | >80 | 150o | SMD2835 | 256 | 50/60 | Triac |
| WP6K-28WVD-V | 1800 | 28 | 130-140lm/w | 3640-3920 | 6000K:6065±415k | >80 | 150o | | 288 | 50/60 | Triac |
| V-Shape(150o) Full Spectrum Broilers Version (Triac Dimmable) |
| WP2K-09WTD-F | 600 | 9 | 110lm/w | 990 |  | >80 | 150o | | | 96 | 50/60 | Triac |
| WP4K-20WTD-F | 1200 | 20 | 110lm/w | 2200 | >80 | 150o | AC100-120V or AC200-240V | 498nm & 625nm | 216 | 50/60 | Triac |
| WP5K-24WTD-F | 1500 | 24 | 110lm/w | 2640 | >80 | 150o | 252 | 50/60 | Triac |
| WP6K-28WTD-F | 1800 | 28 | | 3080 | >80 | 150o | 288 | 50/60 | Triac |
| White+Red Two Colors Switchable for Breeder/ Layers (Triac Dimmable) |
| WP2K-2*09WTD-WR | 600 | 2*9 | Red:50lm/w White:130lm/w red+white: 90-110lm/w | 1620 |   | >80 | | | | 132 | 50/60 | Triac |
| WP4K-2*20WTD-WR | 1200 | 2*20 | 3600 | >80 | 120o/150o | AC100-120V or AC200-240V | 3000K & | 256 | 50/60 | Triac |
| WP5K-2*28WTD-WR | 1500 | 2*28 | 5040 | >80 | 625nm | 320 | 50/60 |
| WP6K-2*30WTD-WR | 1800 | 2*30 | 5400 | >80 | | | | 320 | 50/60 | Triac |
